Crown / Samducksa Knee Lever Neo
Knee's second-generation signature Korean lever with a low-profile 35mm collar, JLF-compatible multi-mount plate, Knee-specific ST-30+ grommet, 16.1mm actuator, mixed Gersung switches, and a clear polycarbonate circle-square guide.
Lever part record — specifications from manufacturer documentation and community verification. Confirm mounting compatibility before ordering.
- Manufacturer
- Crown / Samducksa
- Category
- Lever
- Mount Type
- JLF-standard multi-mounting plate; requires at least 65mm width, 97mm length, and 43mm internal height
- Gate
- Circle-square guide made from clear polycarbonate
- Grommet
- ST-30+; Knee-specific tension rubber
- Microswitches
- 4
At a glance
Key Specs
Mount Type
JLF-standard multi-mounting plate; requires at least 65mm width, 97mm length, and 43mm internal height
Gate
Circle-square guide made from clear polycarbonate
Microswitches
4
Grommet Tension
ST-30+; Knee-specific tension rubber
Technical data
Specifications
- model
- Knee Lever Neo
- priceUsd
- $85.00; clear white and clear violet handles add $5.00
- availability
- Available at IST Mall when checked 2026-06-19
- gate
- Circle-square guide made from clear polycarbonate
- mount
- JLF-standard multi-mounting plate; requires at least 65mm width, 97mm length, and 43mm internal height
- collar
- Low-profile 35mm collar
- grommetTension
- ST-30+; Knee-specific tension rubber
- actuatorDiameterMm
- 16.1
- actuatorMaterial
- Acetal
- shaft
- Stainless steel
- handle
- Clear acrylic capsule-style handle
- handleColors
- Clear red; clear white; clear violet
- housing
- Clear polycarbonate upper housing; clear red polycarbonate lower housing
- bracket
- 1.6T coated and printed iron plate
- microswitches
- 3× Gersung A3KN wide-hinge plus 1× Gersung A3 standard-hinge
- microswitchCount
- 4
- listedStoreWeight
- 0.50kg on IST Mall; may include packaging
